Low Loss OM4 50/125 MPO-8 to LC / MTP 8fibers to LC Fan-out Patch Cable Violet Color Type A Type B Type C

- An OM4 MPO-8 to LC fanout patch cord / MTP 8F to LC fanout cable is a high-density, multi-fiber breakout cable used to connect parallel optical equipment (like 40G QSFP+ or 100G QSFP28 transceivers) into standard LC-connected duplex ports on switches, routers, or patch panels.

- An OM4 MPO-8 to LC fanout patch cord / MTP 8F to LC fanout cable is a high-density fiber optic cable that transitions an 8-fibers MPO/MTP connector into four individual duplex (or eight simplex) LC connectors.

- Featuring an MPO connector on one end and 4 duplex  LC connectors on the other, this breakout cable combines efficiency and versatility, making it ideal for data centers, telecom networks, and enterprise environments.

- Built with OM4 multimode fiber, the cable supports high-speed transmissions at 40G, 100G, 200G, or 400G, ensuring reliable and stable performance. Its uniboot LC connectors reduce cable clutter and allow for reversible polarity, making installation and maintenance more efficient.

- It is explicitly engineered to connect QSFP+ transceivers on high-speed switches to four individual 10G SFP+ ports.

- Key Advantage:

+ Space-Saving Uniboot LC Connectors

* Combines two fibers into a single cable, optimizing airflow in high-density environments.

* Reversible polarity for quick and tool-free adjustments during installation.

+ High-Performance MPO Connector

* High-density interface supports 8 fibers in a single connector.

* Low insertion loss ensures minimal signal degradation.

+ OM4 Multimode Fiber

* Optimized for 850nm wavelength, offering high bandwidth and low attenuation for short-reach data links.

* Enhanced performance for 40G/100G Ethernet applications.

+ LSZH Jacket

* Fire-safe material designed for indoor data center cabling.

* Aqua color for easy identification in multimode networks.

+ Customizable Configurations

* Lengths, connector types, and breakout styles can be tailored to specific project requirements.

* Compatible with various polarity types (A, B, C) for versatile network integration.
